Metal Stud and Track for Drywall System

Size

Thickness（mm）	Width（mm）	Length（mm）	Height（mm）
0.35-1.00	50/70/75/100/150	3000	22-50

Parameters

Both surface galvanization ≥100g/m²	Load Channel(Dimension A) ≤0.5mm
Load Channel(Dimension B) ≤1mm	Side flatness ≤1.5mm/1000mm
Underside flatness ≤1.5mm/1000mm	Angle difference ≤2°00′
Load Channel Remainder distortion limitation2.0mm

Brief Introduction

Metal Stud

and Track for Drywall System
Sanle light weight steel keel is made of high quality cold-rolled hot-dip galvanized steel coil,which is popular by its good quality ,high strength and good rigidity.
Double size zinc coating is in accordance with national standard and fully guarantees it the abilities of rust-proof and corrosion resistance. The metal stud and track is widely use in the drywall system.

Specification details

Features

*Light weight, easy to install, easily removable and maerials can be recycled.
*Raw material is high quality hot dipped zinc galvanized steel , decided that the steel keel have good performance in fireproof and heat insulation, waterproof and anti-rust, anti-corrosive .
*Full range of products and customizable.
* Long using life.
*The whole drywall system has the advantage of light-weight and high strength.

Application

Metal studs are vertical profiles inserted into the tracks, bearing profiles of the partition; used for fixing of partition covering, calcium silciate board, fiber cement board and etc.
Metal tracks are horizontal profiles to fix the partition to floor and ceiling.
It is Suitable for the drywall system in factory, office building, warehouse, greenhouse, home decorations,etc.
